低壓雙級永磁變頻螺桿空壓機

產品優勢 Product Advantages

1、瑞沃斯永磁同步無感電機為IPM同步電機，采用高效釹鐵永磁鐵，無勵磁損耗，經過特殊轉了結構設計，很大降低鐵損與雜散損耗，整機效率達到IE4標準以上，比三相異步電機效率提高5%-10%，效率因數提高10%-15%以上大漠鷹永磁同步無感電機在20%-120%負載范圍內可保持較高的效率與功率因數，功率因數可為1，三相異步電機只能達到0.86，有效降低了線路損耗，輕載節能更為明顯，并提高電網利用率。

The REVOS permanent magnet synchronous non inductive motor is an IPM synchronous motor that uses high-efficiency neodymium iron permanent magnets with no excitation loss. After special structural design, it greatly reduces iron loss and stray loss. The overall efficiency reaches IE4 standard or above, which is 5% -10% higher than that of three-phase asynchronous motors, and the efficiency factor is increased by more than 10% -15%. The Desert Eagle permanent magnet synchronous non inductive motor can maintain high efficiency and power factor in the load range of 20% -120%, with a power factor of 1. The three-phase asynchronous motor can only reach 0.86, effectively reducing line losses, achieving more significant energy saving under light load, and improving the utilization rate of the power grid.

2、在全負載狀態下，同步無感永磁電機可以在小能耗下產出大氣量，并且當負載率低于20%時，仍然能保證此效率同步無感永磁電機在整個氣量調節速度范圍內始終保持高達95%的運行效率。

At full load, the synchronous non inductive permanent magnet motor can produce the maximum air volume with minimal energy consumption, and can still ensure this efficiency even when the load rate is below 20%. The synchronous non inductive permanent magnet motor maintains an operating efficiency of up to 95% throughout the entire air volume regulation speed range.
